2–5

Command Word/Bit Descriptions

Publication 1771-6.5.126 – March 1998

DYC

Word

Bit

Description

DYC02

Action Execution Commands
Bits DYC01-B08 - DYC01-B15 and all 16 bits in DYC02 are the 24 action execution commands to control the module. Be-
cause the module cannot respond to more than one action execution command at a time, it ceases all action execution and
sets its outputs to zero when it decodes a valid Dynamic Command Block with more than one of these SET. The module
senses this invalid request and latches alarm status bit SYS14-B00, and unlatches SYS14-B00 when it decodes a valid Dy-
namic Command Block having one or none of the action execution bits SET.

B00-03

RFU

4

Ram (Screw) Profiles Execution Commands
Bits DYC02-B04 - DYC02-B09 are the six action execution commands available to initiate all profiled ram (screw) movements
(including both decompression movements). You may logically link all six in a single integrated machine movement if all three
Logical Bridge Bits are RESET. These three bits are:
HPC03-B08 - Link Inj/Pack/Hold and Pre-decompress (Inj/Pack/Hold always linked)
HPC03-B09 - Link Pre-decompress and Plastication
PPC03-B08 - Link Plastication and Post-decompress
If all three of these bits are RESET, transfer only DYC02-B04 to the module to force the entire Ram (Screw) portion of an
automatic machine cycle.

B04

= 0 Normal
= 1 Execute Injection Profile
A false-to-true transition of this bit forces the module to do one of the following, attempted in the order listed.

if:

then the module:

any of SYS07-B00 through B05 are SET

ignores any profile commands

SYS15-B08 is RESET

latches SYS13-B05

either of the following are true:
– ram (screw) position exceeds non-zero IPC61
– IPC61 is zero

terminates any action in progress and
starts the Injection Profile

both of the following are true:
– ram (screw) position equals or is less than non-zero IPC61
– HPC11 is not zero

terminates any action in progress and
starts the Pack Profile

both of the following are true:
– ram (screw) position equals or is less than non-zero IPC61
– HPC11 is zero

terminates any action in progress and
starts the Hold Profile

B05

if:

then the module:

= 0 Normal
= 1 Execute Pack Profile
A false-to-true transition of this bit forces the module to do one of the following, attempted in the order listed.

if:

then the module:

any of SYS07-B00 through B05 are SET

ignores any profile commands

SYS15-B11 is RESET

latches SYS13-B06

HPC11 is not zero

terminates any action in progress and
starts the Pack Profile

HPC11 is zero

terminates any action in progress and
starts the Hold Profile

B06

= 0 Normal
= 1 Execute Hold Profile
A false-to-true transition of this bit forces the module to do one of the following, attempted in the order listed.

if:

then the module:

any of SYS07-B00 through B05 are SET

ignores any profile commands

SYS15-B11 is RESET

latches SYS13-B07

this bit (B06) is SET

terminates any action in progress and
starts the Hold Profile
