1–17 Abbreviated Command and Status Blocks
Publication 1771-6.5.126 – March 1998
Injection Profile Actuals
IPS09 N44:601 Segment 1 velocity
IPS10 N44:602 Segment 1 pressure
IPS11 N44:603 Segment 1 execution time
IPS12 N44:604 End of Segment 1 position
IPS13 N44:605 Segment 2 velocity
IPS14 N44:606 Segment 2 pressure
IPS15 N44:607 Segment 2 execution time
IPS16 N44:608 End of Segment 2 position
IPS17 N44:609 Segment 3 velocity
IPS18 N44:610 Segment 3 pressure
IPS19 N44:611 Segment 3 execution time
IPS20 N44:612 End of Segment 3 position
IPS21 N44:613 Segment 4 velocity
IPS22 N44:614 Segment 4 pressure
IPS23 N44:615 Segment 4 execution time
IPS24 N44:616 End of Segment 4 position
IPS25 N44:617 Segment 5 velocity
IPS26 N44:618 Segment 5 pressure
IPS27 N44:619 Segment 5 execution time
IPS28 N44:620 End of Segment 5 position
IPS29 N44:621 Segment 6 velocity
IPS30 N44:622 Segment 6 pressure
IPS31 N44:623 Segment 6 execution time
IPS32 N44:624 End of Segment 6 position
IPS33 N44:625 Segment 7 velocity
IPS34 N44:626 Segment 7 pressure
IPS35 N44:627 Segment 7 execution time
IPS36 N44:628 End of Segment 7 position
IPS37 N44:629 Segment 8 velocity
IPS38 N44:630 Segment 8 pressure
IPS39 N44:631 Segment 8 execution time
IPS40 N44:632 End of Segment 8 position
IPS41 N44:633 Segment 9 velocity
IPS42 N44:634 Segment 9 pressure
IPS43 N44:635 Segment 9 execution time
IPS44 N44:636 End of Segment 9 position
IPS45 N44:637 Segment 10 velocity
IPS46 N44:638 Segment 10 pressure
IPS47 N44:639 Segment 10 execution time
IPS48 N44:640 End of Segment 10 position
IPS49 N44:641 Segment 11 velocity
IPS50 N44:642 Segment 11 pressure
IPS51 N44:643 Segment 11 execution time
IPS52 N44:644 RFU
Maximum Pressures During Injection
IPS53 N44:645 Ram (screw)
IPS54 N44:646 Cavity
IPS55-60 N44:647-652 RFU
