2–16 Command Word/Bit Descriptions
Publication 1771-6.5.126 – March 1998
Notes: For [ ] engineering units, see page 2.
Bit-mapped Control Words
Word Bit Description
INC01 Block ID = 00001000 (Low byte). High byte reserved for the module. Do not use.
INC02 Configuration Selections
B00-02 Selected Velocity Control Valve
The module uses its algorithm to drive the following output during any Vel/Pos or LimVel/Pos Injection Profile.
B02 B01 B00
0 0 0 Output #1
0 0 1 Output #2
0 1 0 Output #3
0 1 1 Output #4
1 x x Invalid
B03 RFU
B04-06 Selected Pressure Control Valve
The module uses its algorithm to drive the following output during any Press/Pos or Press/Time Injection Profile.
B06 B05 B04
0 0 0 Output #1
0 0 1 Output #2
0 1 0 Output #3
0 1 1 Output #4
1 x x Invalid
B07 Pressure Algorithm Selection
= 0 Dependent Gains (ISA)
= 1 Independent Gains (A-B)
B08-15 RFU
INC03 - 04 RFU
Expert Response Compensation (ERC) Percentage
Word Description
INC05 Minimum Velocity Control ERC Percentage [31]
Although error coding allows range of 00000 to 09999, the module limits it to a minimum of 01000.
INC06 Minimum Pressure Control ERC Percentage [31]
Although error coding allows range of 00000 to 09999, the module limits it to a minimum of 01000.
INC07, 08 RFU
Unselected Valve Set-output Values
When the module starts the Injection Profile, it:
•
ignores the unselected value of the selected output
•
uses ramp rates INC17-20 and INC25-28 to ramp unselected outputs
•
sets its unselected outputs to the values listed below
Word Description
INC09 Output #1 Set-output Value during Profile [19]
INC10 Output #2 Set-output Value during Profile [19]
INC11 Output #3 Set-output Value during Profile [19]
INC12 Output #4 Set-output Value during Profile [19]
INC13-16 RFU
INC – Injection
Configuration Block
