1–15 Abbreviated Command and Status Blocks
Publication 1771-6.5.126 – March 1998
ERC Values for Hold Profile
RLC25 N44:561 Hold segment 1
RLC26 N44:562 Hold segment 2
RLC27 N44:563 Hold segment 3
RLC28 N44:564 Hold segment 4
RLC29 N44:565 Hold segment 5
ERC Values for Plastication Profile
RLC30 N44:566 Plastication segment 1
RLC31 N44:567 Plastication segment 2
RLC32 N44:568 Plastication segment 3
RLC33 N44:569 Plastication segment 4
RLC34 N44:570 Plastication segment 5
RLC35 N44:571 Plastication segment 6
RLC36 N44:572 Plastication segment 7
RLC37 N44:573 Plastication segment 8
RLC38 N44:574 Plastication segment 9
RLC39 N44:575 Plastication segment 10
RLC40 N44:576 Plastication segment 11
RLC41-64 N44:577-600 RFU
Word Pro-Set Address Description
Bit-mapped Status Words
HPS01 B34:0 Block ID 00000100 (lower byte)
HPS01 B34:0 Jog status (upper byte)
HPS02 B34:1 Status of profile execution
HPS03 B34:2 Miscellaneous status
HPS04 B34:3 Status of watchdog timers
HPS05-06 B38:44-45 RFU
HPS07 B38:46 CV high limit alarms
HPS08 B38:47 CV low limit alarms
Actuals from Pack Profile
HPS09 N44:657 Segment 1 cavity pressure
HPS10 N44:658 Segment 1 ram (screw) pressure
HPS11 N44:659 End of Segment 1 position
HPS12 N44:660 Segment 2 cavity pressure
HPS13 N44:661 Segment 2 ram (screw) pressure
HPS14 N44:662 End of Segment 2 position
HPS15 N44:663 Segment 3 cavity pressure
HPS16 N44:664 Segment 3 ram (screw) pressure
HPS17 N44:665 End of Segment 3 position
HPS18 N44:666 Segment 4 cavity pressure
HPS19 N44:667 Segment 4 ram (screw) pressure
HPS20 N44:668 End of Segment 4 position
HPS21 N44:669 Segment 5 cavity pressure
HPS22 N44:670 Segment 5 ram (screw) pressure
HPS23 N44:671 End of Segment 5 position
HPS24-25 N44:672 RFU
HPS – Pack/Hold Profile
Status Block
