4.2 Transmitting Documents Through a Relay Station (Relay Broadcast)
49
B
roadc
ast Sen
d
4
4
Enter the following format on the keyboard displayed on the touch
panel.
● Use the keyboard on the touch panel to enter symbols like “!” or “
∗
”. For details on how to enter
symbols, see “1.5 Entering Text” (P. 8).
● Destinations for up to 20 relay stations can be specified.
5
Press Start.
Scanning and transmission begins.
4.2.4 F Code Method
In the F Code method, you can do Relay Broadcast Send by doing the following
operations.
When the machine is used as an initiating station, to do Relay Broadcast Send,
check the F Code (sub-address) to the relay station and the necessary pass-
words.
When the machine is used as a relay station, to do Relay Broadcast Send, trans-
mit the F Code (sub-address) to the initiating station and the necessary pass-
words.
When doing Relay Broadcast Send with the F Code method, to use the password set the receive pass-
word for the relay station.
● When doing Relay Broadcast Send among these types of machines, we recommend using the fax
signal method.
● When using a machine that is different from this machine as a relay station, check the F Code sub-
address and password of the targeted destination.
When this machine is a relay station, the F Code that is transmitted to the initiat-
ing station is as follows.
Relay Broadcast
Send Print
directive Relay
station ID Address
Number Address
Number Address
Number
....
Up to 20 digits
Relay station
telephone
number
Confirm the
facsimile tone Confirm the
continuous,
short high-pitched
tone Password Relay
station
ID
Address
Number
The continuous,
short high-pitched
tone sounds
