1.3
Telephone Line
Connectors
The figure below shows the telephone line connectors at the rear side of the machine.
US/Canada: Line 2 and 4 can be specified when an option is installed.
Europe: Line 1 only.
1 LINE 1 Connect the fax to a public switched telephone network (PSTN). An
external telephone cannot be connected.
2 TEL An external telephone is connected here.
3 LINE 2 (Line 2) Connect to a public line.
4 LINE 4 (Line 4) Connect to a public line.
1
2
4
3
