Page 25: Customize paper supply screen -5

Current Setting
Item
8.5” x13” SE
Paper size 17
9” X11” LE
Paper size 18
B4 SE
Paper size 19
B5 SE
Paper size 20
The following alternate sizes can display for selection when paper is loaded in Tray 5:
• A/B Series Size – A3, A4, A4, A5, A5, A6, B4, B5,B5,B6
• Inch Size includes – 13x19”, 13x18,”12.6X19.2,” 12X18,”, 11X17,”11X15”, 8.5X14,”
8.5X13,” 8.5X11,” 8.5X11,” 8X10,” 8X10”, 7.25X10.5”, 7.25X10.5”, 5.5X8.5”, 5X7”
• Others – SRA3, A4 Cover, 9x11, 215x315, 8K, 16K, 16K, 100x 148mm, 148x 200mm,
4x6”, Env 120x235, Env 240x332, Env 229x324, Env 162x229
• Custom Size
Setting Paper Size Defaults
To define and set the paper sizes that will display when Tray 5 is loaded:
1.
At the printer Control Panel, make sure to log in as Administrator and then
screen.
2.
From the Paper Tray Settings area, select Tray 5 - Paper Size Defaults
3.
Use the up or down arrow to select the option you want to change.
4.
Touch Change Setting
5.
Select the desired feature you want. Select from A/B Series Size, Inch Size, Others,
or Custom Size.
6.
Touch Save > Close.
Customize Paper Supply Screen
From the Paper Tray Settings area, use this feature to select whether the setting items
specified in Paper Size or Auto Paper Select under Paper Tray Attributes will display on
the Paper Supply screen.
1.
At the printer Control Panel, make sure to log in as Administrator and then
screen.
2.
Select Customize Paper Supply screen.
3.
Select the desired option:
• Usage - Displays the setting in Auto Paper Select.
• Disabled - does not display the items specified in Paper Size.
• Size Detection - Displays the setting in Paper Size.
3-5
Xerox
®
Color 550/560/570 Printer
System Administrator Guide
Paper Tray Settings
