APPENDIX
E
©2007-2013 Physio-Control, Inc. LIFEPAK 15 Monitor/Defibrillator Operating Instructions
E-1
Symbols
The symbols in Table E-1 may be found in these operating instructions or on the LIFEPAK 15
monitor/defibrillator, its accessories, packaging, or training tools.
Table E-1 Symbols
SYMBOL DESCRIPTION
Device or User Interface
Attention, consult accompanying documents
Alarm on
Alarm off
VF/VT alarm on
VF/VT alarm is on, but is silenced or suspended
Battery in well, fully charged. For a description of all battery indicators, see
"Battery Status Indicators" on page 3-20.
Heart rate/pulse rate indicator
Bluetooth wireless technology
Shock count (x) on screen
Shock button on front panel or hard paddles
Auxiliary power indicator
Battery charging indicator
Service indicator
Greater than
Less than
Joules
(x)
J
