APPENDIX
A
©2007-2013 Physio-Control, Inc. LIFEPAK 15 Monitor/Defibrillator Operating Instructions
A-9
Maximum Time from Initiation of Analysis to Shock Ready (AED Mode):
Battery Status Charge Time
Fully charged 200 J within 15 seconds, nominal
Fully charged, followed by 15
full-energy shocks 360 J within 30 seconds
Fully charged 360 J within 30 seconds
Maximum Time from Power-on to Shock Ready (Manual Mode):
Battery Status Charge Time
Fully charged, followed by 15
full-energy shocks 360 J within 25 seconds
Maximum Time from Power-on to Shock Ready (AED Mode):
Battery Status Charge Time
Fully charged, followed by 15
full-energy shocks 360 J within 40 seconds
Manual Mode
Energy Select 2, 3, 4, 5, 6, 7, 8, 9, 10, 15, 20, 30, 50, 70, 100, 125, 150, 175,
200, 225, 250, 275, 300, 325, and 360 joules
Synchronous
cardioversion The maximum time delay between synchronization pulse and the delivery
of energy, once the output has been activated, is not more than 60 msec.
This time delay is measured from the peak of the QRS to the peak of the
defibrillator waveform.
Paddles Lead Off
Sensing The transition point at which device changes from assuming that QUIK-
COMBO electrodes are properly connected to patient to assuming that
electrodes are not connected is 300±50
.
Biphasic Waveform Biphasic Truncated Exponential
The following specifications apply from 25 to 200
, unless otherwise
specified:
Energy Accuracy: ±1 joule or 10% of setting, whichever is greater, into
50
±2 joules or 15% of setting, whichever is greater, into 25-175.
Voltage Compensation: Active when disposable therapy electrodes are
attached. Energy output within ±5% or ±1 joule, whichever is greater, of
50
 value, limited to the available energy which results in the delivery of
360 joules into 50

Table A-1 LIFEPAK 15 Monitor/Defibrillator Specifications (Continued)
CHARACTERISTIC DESCRIPTION
