DATA MANAGEMENT
7
©2007-2013 Physio-Control, Inc. LIFEPAK 15 Monitor/Defibrillator Operating Instructions
7-5
Note: When CODE SUMMARY reports are transmitted, they are always sent in the long format.
Transmitted CODE SUMMARY reports do not include the Trend Summary.
The CODE SUMMARY report always contains the Preamble and the Event/Vital Sign Log. See
Figure 7-1 for an example.
Figure 7-1 CODE SUMMARY Report
Preamble
The preamble consists of patient information (name, patient ID, age, and sex) and device
information (date, time, and therapy information) as shown in Figure 7-1. The defibrillator
automatically enters a unique identifier in the ID field for each Patient Record. This identifier is
composed of the date and time that the defibrillator is turned on. The Incident field allows you
to enter up to 14 alpha-numeric characters to link the device to other documents such as an
EMS Run Report.
Event/Vital Sign Log
The LIFEPAK 15 monitor/defibrillator documents events and vital signs in chronological order.
Events are operator or device actions, such as actions that are related to monitoring, pacing,
AED therapy, or data transmission. Values for each active vital sign are entered into the log
automatically every 5 minutes and for each event. Figure 7-2 lists events that may be found in
the Event Log.
Name: Lee, William
Record ID:
Patient ID:
Incident:
Age: 50
Sex: M
critical event record
Power On:
Device:
Site:
Total Shocks:
Total Time Paced:
Total 12-leads:
COMMENTS:
Time Event HR SpO2•PR SpCO SpMet EtCO2(mmHg)•RR NIBP•PR P1 P2
ART
CVP
Power On
Initial Rhythm
Vital Signs
NIBP
Pacing 1 Started
Pacing 2 Set
Intubation
Vital Signs
Pacing 3 Stopped
Alarm HR
Vital Signs
CPR: No Airway 30:2
Metronome Off
Shock 1 200J
Shock 2 200J
Preamble Event/Vital Sign Log
24 Apr 07
