DATA TRANSMISSION
8
©2007-2013 Physio-Control, Inc.
LIFEPAK 15 Monitor/Defibrillator Operating Instructions
8-5
Using Bluetooth Wireless Communication
Bluetooth technology is a short-range wireless communication technology that is available as an
option on the LIFEPAK 15 monitor/defibrillator. When Bluetooth technology is installed, the
Bluetooth icon appears on the Home Screen. See Figure 8-2.
For more information about supported Bluetooth technologies, see www.physio-control.com.
A Bluetooth connection between the LIFEPAK 15 monitor and a target device is always initiated
from the LIFEPAK 15 monitor.
Figure 8-2 Bluetooth Icon on the Home Screen
The Bluetooth icon shows the status of the wireless connectivity in the device.
Table 8-1 Bluetooth Status
BLUETOOTH ICON
DESCRIPTION
The Bluetooth LED is illuminated when the Bluetooth feature is enabled in this
device and this device is connected to another Bluetooth-enabled device.
The Bluetooth icon appears but the LED is not illuminated when the Bluetooth
feature is enabled in this device, but this device is currently not connected to
another Bluetooth-enabled device.
A red X appears when the Bluetooth feature is installed in this device, but
wireless communication is currently set to OFF or there is a Bluetooth
malfunction. See Table 8-3 on page 8-15.
Bluetooth icon
J
HR
SP02 %
CO2 mmHg
ART
mmHg
CVP
mmHg
NIBP
mmHg
150
50
