APPENDIX
A
©2007-2013 Physio-Control, Inc. LIFEPAK 15 Monitor/Defibrillator Operating Instructions
A-3
PHYSICAL
Weight Basic monitor/defibrillator with new roll paper and two batteries
installed: 8.6 kg (18.9 lb)
Fully featured monitor/defibrillator with new roll paper and two batteries
installed: 9.1 kg (20.1 lb)
Lithium-ion battery: < 0.60 kg (1.3 lb)
Accessory bags and shoulder strap: 1.77 kg (3.9 lb)
Standard (hard) paddles: 0.95 kg (2.1 lb)
Height 31.7 cm (12.5 in)
Width 40.1 cm (15.8 in)
Depth 23.1 cm (9.1 in)
DISPLAY
Size
(active viewing area) 212 mm (8.4 in) diagonal; 171 mm (6.7 in) wide x 128 mm (5.0 in)
high
Display Type 640 dot x 480 dot color backlit LCD
User selectable display mode (full color or SunVue™ high contrast)
Displays a minimum of 5 seconds of ECG and alphanumerics for values,
device instructions, or prompts
Displays up to three waveforms
Waveform display sweep speed: 25 mm/sec for ECG, SpO
2
, IP, and
12.5 mm/sec for CO
2
DATA MANAGEMENT
The device captures and stores patient data, events (including waveforms and annotations), and
continuous waveform and patient impedance records in internal memory.
The user can select and print reports, and transfer the stored information via supported
communication methods.
Report
Types Three format types of CODE SUMMARY™ critical event record:
short, medium, and long
12-lead ECG with STEMI statements
Continuous Waveform (transfer only)
Trend Summary
Vital Sign Summary
Snapshot
Memory Capacity Total capacity is 360 minutes of continuous ECG, 90 minutes of
continuous data from all channels, or 400 single waveform events.
Maximum memory capacity for a single patient includes up to 200 single
waveform reports and 90 minutes of continuous ECG.
Table A-1 LIFEPAK 15 Monitor/Defibrillator Specifications (Continued)
CHARACTERISTIC DESCRIPTION
