BASIC ORIENTATION
3
©2007-2013 Physio-Control, Inc. LIFEPAK 15 Monitor/Defibrillator Operating Instructions
3-7
Area 3
Figure 3-4 Area 3 Controls
Table 3-3 Area 3 Controls
CONTROL DESCRIPTION FOR MORE INFORMATION
NIBP Initiates blood pressure measurement. LED
illuminated when BP measurement is being
obtained. See page 4-37
ALARMS Activates and silences alarms. LED illuminated
when alarms are enabled and flashes when an alarm
condition occurs. See page 3-21
OPTIONS Accesses optional functions. See page 3-23
EVENT Accesses user-defined events. See page 3-25
HOME SCREEN Returns to Home Screen display. See page 3-17
SPEED DIAL Scrolls through and selects screen or menu items. See page 3-19
Display mode button switches between color display
and high contrast SunVue™ display.
NIBP
ALARMS
OPTIONS
EVENT
HOME
SCREEN
Speed dial
