POWER ADAPTER
9
©2007-2013 Physio-Control, Inc. LIFEPAK 15 Monitor/Defibrillator Operating Instructions
9-7
Output Extension Cable with Breakaway Connector
One optional output extension cable may be connected between the power adapter and the power
adapter output cable, if desired. The output extension cable is equipped with a breakaway
connector that can be pulled apart without manually rotating the lock ring. With the breakaway
connector, you can quickly separate the monitor/defibrillator from the power adapter without
damaging the cables or connectors.
To use the breakaway feature, the power adapter and output extension cable must be secured as
described in the Power Adapter Instructions for Use. The breakaway connector is designed to
withstand routine breakaway use. However, to prolong the life of the connector, manually
disconnect it whenever possible.
To order the output extension cable, contact your Physio-Control representative or order online at
store.physio-control.com.
IMPORTANT! Do not use more than one output extension cable.
Figure 9-3 Output Extension Cable with Breakaway Connector
Breakaway Connector Output Extension Cable
Power Adapter
Output Cable
