CHAPTER 5 CLOCK GENERATOR
User’s Manual U15331EJ4V1UD
99
(2) Subclock oscillation mode register (SCKM)
SCKM selects a feedback resistor for the subsystem clock, and controls the oscillation of the clock.
SCKM is set with a 1-bit or 8-bit memory manipulation instruction.
RESET input sets SCKM to 00H.
Figure 5-4. Format of Subclock Oscillation Mode Register
Feedback resistor selection Note
0 0 0 0 0 0 FRC SCC SCKM
Symbol Address After reset R/W
FFF0H 00H R/W
7 6 5 4 3 2 1 <0>
FRC
0
1
On-chip feedback resistor used
On-chip feedback resistor not used
Control of subsystem clock oscillator operation SCC
0
1
Operation enabled
Operation disabled
Note The feedback resistor is necessary to adjust the bias point of the oscillation waveform to close to the mid
point of the supply voltage. When the subclock is not used, the power consumption in STOP mode can be
further reduced by setting FRC = 1.
Caution Bits 2 to 7 must be set to 0.
(3) Subclock control register (CSS)
CSS specifies whether the main system or subsystem clock oscillator is to be selected. It also specifies the
CPU clock operation status.
CSS is set with a 1-bit or 8-bit memory manipulation instruction.
RESET input sets CSS to 00H.
Figure 5-5. Format of Subclock Control Register
CPU clock operation status
0 0 CLS CSS0 0 0 0 0 CSS
Address After reset R/W
FFF2H 00H R/W
7 6 5 4 3 2 1 0
CLS
0
1
Operation based on the output of the (divided) main system clock
Operation based on the subsystem clock
Selection of the main system or subsystem clock oscillator CSS0
0
1
(Divided) output from the main system clock oscillator
Output from the subsystem clock oscillator
Symbol
Note
Note Bit 5 is read only.
Caution Bits 0 to 3, 6, and 7 must be set to 0.
