CHAPTER 17 STANDBY FUNCTION

312

User’s Manual U15331EJ4V1UD

17.2.2 STOP mode


(1) Setting and operation status of STOP mode

The STOP mode is set by executing the STOP instruction.

Caution Because the standby mode can be released by an interrupt request signal, the standby

mode is released as soon as it is set if there is an interrupt source whose interrupt request
flag is set and interrupt mask flag is reset. When the STOP mode is set, therefore, the
HALT mode is set immediately after the STOP instruction has been executed, the wait time
set by the oscillation stabilization time selection register (OSTS) elapses, and then the
operation mode is set.

The operation statuses in the STOP mode are shown in the following table.

Table 17-3. Operation Statuses in STOP Mode

STOP Mode Operation Status During Main System Clock Operation

Item

Subsystem Clock Operating

Subsystem Clock Stopped

Main system clock

Oscillation stopped

Subsystem clock

×4

multiplication circuit

Operation stopped

CPU Operation

stopped

Ports (output latches)

Status before STOP mode setting retained

16-bit timer 20

Operation stopped

8-bit timer 50

Operable

Note 1

Operable

Note 2

8-bit timer 60

Operable

Note 3

8-bit timer 61

Operable

Note 3

Watch timer

Operable

Note 4

Operation

stopped

Watchdog timer

Operation stopped

Key return circuit

Operable

Serial interface 20

Operable

Note 5

Serial interface 1A0

Operable

Note 5

LCD controller/driver

Operable

Note 4

Operation

stopped

A/D converter

Operation stopped

Multiplier Operation

stopped

Remote controller
receiver

Note 6

Operable

Note 4

Operation

stopped

External interrupts

Operable

Note 7

Notes 1. Operation is enabled when either the subsystem clock or the input signal from the timer 60 (when timer

60 is operable) is selected as the count clock.

2. Operation is enabled when the input signal from timer 60 (when timer 60 is operable) is selected as the

count clock.

3. Operation is enabled when the external input clock is selected as the count clock.

4. Operation is enabled when the subsystem clock is selected.

5. Operation is enabled only for a maskable interrupt that is not masked.

6.

µPD789489 and 78F9489 only

7. Operation is enabled only for a maskable interrupt that is not masked.
