User’s Manual U15331EJ4V1UD
7
Major Revisions in This Edition
Page Description
Throughout
Change of descriptions of
µ
PD789489, 78F9489
• Change of status from under development to development completed
• Change of the subseries name to “
µ
PD789489 subseries”
pp.31 to 33
Update of 1.5 78K/0S Series Lineup to latest version
p.123 Modification
of
Figure 7-2 Block Diagram of Timer 50
p.124 Modification
of
Figure 7-3 Block Diagram of Timer 60
Modification of Figure 7-5 Block Diagram of Output control circuit (Timer 60)
p.126
Addition of descriptions in 7.2 (2) 8-bit compare register 60
p.127
Addition of descriptions in 7.2 (4) 8-bit H width compare registers 60 and 61
p.136 Modification
of
Figure 7-11 8-bit Timing of Interval Timer Operation with 8-Bit Resolution (Basic Operation)
p.137 Modification
of
Figure 7-13. Timing of Interval Timer Operation with 8-Bit Resolution (When CRnm Is Set to
FFH)
p.140 Modification
of
Figure 7-17. Timing of Operation of External Event Counter with 8-Bit Resolution
p.150
Addition of descriptions of setting sequence in 7.4.3 Operation as carrier generator
p.151 Modification
of
Figure 7-22. Timing of Carrier Generator Operation (When CR60 = N, CRH60 = M (M > N))
p.152 Modification
of
Figure 7-23. Timing of Carrier Generator Operation (When CR60 = N, CRH60 = M (M < N))
p.153 Modification
of
Figure 7-24. Timing of Carrier Generator Operation (When CR60 = CRH60 = N)
pp.154 to
157
Modification of the mode name in 7.4.4 PWM output mode operation (timer 50)
pp.158, 159
Modification of the mode name in 7.4.5 PPG output mode operation (timer 60 and 61)
p.160 Modification
of
(1) Error on starting timer in 7.5 Cautions on Using 8-Bit Timers 50, 60, and 61
p.174 Modification
of
Figure 10-1. Block Diagram of 10-bit A/D converter
p.182 Modification
of (1) Current consumption in standby mode in 10.5 Cautions Related to 10-Bit A/D Converter
p.187 Modification
of
Figure 11-1. Block Diagram of Serial Interface 20
p.190 Addition
of Caution in Figure 11-3 Format of Serial Operation Mode Register 20
p.194 Modification
of
Cautions in Figure 11-6 Format of Baud Rate Generator Control Register 20
pp.195, 203
Modification of Caution in Table 11-3 and 11-5. Example of Relationship Between System Clock and Baud
Rate
p.222
Modification of descriptions in Figure 12-4. Format of Automatic Data Transmit/Receive Interval
Specification Register 0
pp.342 to
361
Addition of formal specifications of
µ
PD789489 and 78F9489 in CHAPTER 22 ELECTRICAL SPECIFICATIONS
(
µ
PD789488, 78F9488, 789489, 78F9489)
pp.366, 367
Addition of recommended conditions for
µ
PD789489 and 78F9489 in CHAPTER 25 RECOMMENDED
SOLDERING CONDITIONS
Major Revisions in Modified Edition (U15331EJ4V1UD00)
Throughout
Addition of the lead-free products
pp.254, 257
Modification of descriptions of the voltage boost wait time in CHAPTER 13 LCD CONTROLLER/DRIVER
pp.328 Modification
of
Figure 19-9. Wiring Example for Flash Writing Adapter with 3-Wire Serial I/O with
Handshake
The mark shows major revised points.
