364
User’s Manual U15331EJ4V1UD
CHAPTER 24 PACKAGE DRAWINGS
80-PIN PLASTIC QFP (14x14)
NOTE
Each lead centerline is located within 0.13 mm of
its true position (T.P.) at maximum material condition.
ITEM MILLIMETERS
A
B
D
G
17.20 ± 0.20
14.00 ± 0.20
0.13
0.825
I
17.20 ± 0.20
J
C 14.00 ± 0.20
H 0.32 ± 0.06
0.65 (T.P.)
K 1.60 ± 0.20
P 1.40 ± 0.10
Q 0.125 ± 0.075
L 0.80 ± 0.20
F 0.825
N 0.10
M 0.17
+ 0.03
− 0.07
P80GC-65-8BT-1
S 1.70 MAX.
R 3 °+ 7 °
− 3 °
41 60
40 61
21 80
20 1
S
S N
J
detail of lead end
C D
A
B
R
K
M
L
P
I
S
Q
G
F
M H
