Managing Faults 43
INFO or WARNING: message
In CODE EXAMPLE: POST Error Message on page 43 , POST reports a memory error
at FB-DIMM location /SYS/MB/CPU0/CMP0/BR1/CH0/D0. The error was detected
by POST running on core 7, strand 2.
Perform further investigation if needed.
■ If POST detects a faulty device, the fault is displayed and the fault information is
passed to the service processor for fault handling. Faulty FRUs are identified in
fault messages using the FRU name.
■ The fault is captured by the service processor, where the fault is logged, the
Service Required LED is lit, and the faulty component is disabled. See
CODE EXAMPLE: Fault Detected by POST on page 48 .
■ Run the ILOM show faulty command to obtain additional fault information.
In this example, /SYS/MB/CPU0/CMP0/BR1/CH0/D0 is disabled. The system can
boot using memory that was not disabled until the faulty component is replaced.
Note – You can use ASR commands to display and control disabled components. See
“Disabling Faulty Components” on page 50 .
Related Information
■ “Diagnostic Flowchart” on page 11
CODE EXAMPLE: POST Error Message
7:2>
7:2>ERROR: TEST = Data Bitwalk
7:2>H/W under test = /SYS/MB/CPU0/CMP0/BR1/CH0/D0
7:2>Repair Instructions: Replace items in order listed by 'H/W
under test' above.
7:2>MSG = Pin 149 failed on /SYS/MB/CPU0/CMP0/BR1/CH0/D0 (J792)
7:2>END_ERROR
7:2>Decode of Dram Error Log Reg Channel 2 bits
60000000.0000108c
7:2> 1 MEC 62 R/W1C Multiple corrected
errors, one or more CE not logged
7:2> 1 DAC 61 R/W1C Set to 1 if the error
was a DRAM access CE
7:2> 108c SYND 15:0 RW ECC syndrome.
7:2>
7:2> Dram Error AFAR channel 2 = 00000000.00000000
7:2> L2 AFAR channel 2 = 00000000.00000000
