Identifying Server Components
This section provides an overview of the server, including major boards and
components, as well as front and rear panel features.
Related Information
■ “Server Components” on page 173
Infrastructure Boards and Cables
The SPARC Enterprise T5440 server is based on a 4U chassis.
The SPARC Enterprise T5440 server has the following boards installed in the chassis:
■ Motherboard – The motherboard includes slots for up to four CMP modules and
four memory modules, memory control subsystem, up to eight PCIe expansion
slots, and a service processor slot. The motherboard also contains a top cover
safety interlock (“kill”) switch.
Note – 10-Gbit Ethernet XAUI cards are shared in Slots 4 and 5.
■ CMP module – Each CMP module contains an UltraSPARC T2 Plus chip, slots for
four FB-DIMMs, and associated DC-DC converters.
Description Links
Overview of the infrastructure boards and
cables in the server “Infrastructure Boards and Cables” on
page 1
Overview of front panel features “Front Panel Diagram” on page 3
“Front Panel LEDs” on page 4
Overview of rear panel features “Rear Panel Diagram” on page 5
“Rear Panel LEDs” on page 7
“Ethernet Port LEDs” on page 8
