Servicing Customer-Replaceable Units 105
▼ Remove FB-DIMMs
Before you begin, complete these tasks:
■ Read the section, “Safety Information” on page 59 .
■ Power off the server, using one of the methods described in the section, “Powering
Off the System” on page 63 .
■ “Extend the Server to the Maintenance Position” on page 66
■ “Perform Electrostatic Discharge – Antistatic Prevention Measures” on page 69
■ “Remove the Top Cover” on page 69
■ “Remove a CMP/Memory Module” on page 99
Do the following:
1. If you are removing a faulty FB-DIMM, determine which FB-DIMM you want
to remove.
a. Press the FB-DIMM fault button.
See “FB-DIMM Fault Button Locations” on page 113 .
b. Note which FB-DIMM fault LED is illuminated.
2. Push down on the ejector tabs on each side of the FB-DIMM until the
FB-DIMM is released.
Caution – FB-DIMMs might be hot. Use caution when servicing FB-DIMMs.
3. Grasp the top corners of the faulty FB-DIMM and remove it from the
CMP/memory module.
4. Place the FB-DIMM on an antistatic mat.
5. Repeat Step 2 through Step 4 to remove any additional FB-DIMMs.
▼ Install FB-DIMMs
1. Unpackage the replacement FB-DIMMs and place them on an antistatic mat.
Tip – See “Supported FB-DIMM Configurations” on page 110 for information about
configuring the FB-DIMMs.
2. Ensure that the ejector tabs are in the open position.
