Supported CMP/Memory Module Configurations
TABLE: Supported CMP/Memory Module Configurations on page 104 shows the
supported CMP/memory module configurations, as viewed from the front of the
server.
Related Information
■ “CMP and Memory Module Device Identifiers” on page 103
■ “Performing Node Reconfiguration” on page 155
Servicing FB-DIMMs
Up to 16 FB-DIMMs can be installed in each CMP/memory module pair.
Related Information
■ “Managing Faults” on page 9
■ “Remove FB-DIMMs” on page 105
■ “Install FB-DIMMs” on page 105
■ “Verify FB-DIMM Replacement” on page 106
■ “Add FB-DIMMs” on page 109
■ “Supported FB-DIMM Configurations” on page 110
■ “FB-DIMM Device Identifiers” on page 112
■ “FB-DIMM Fault Button Locations” on page 113
■ “Servicing CMP/Memory Modules” on page 98
■ “Performing Node Reconfiguration” on page 155
TABLE: Supported CMP/Memory Module Configurations
Configuration
CMP3
MEM3 CMP1
MEM1 CMP2
MEM2 CMP0
MEM0
One CMP/memory pair X
Two CMP/memory pairs X X
Three CMP/memory pairs X X X
Four CMP/memory pairs
(full configurations) X X X X
