96 SPARC Enterprise T5440 Server Service Manual • July 2009
PCIe Device Identifiers
TABLE: PCIe Device Identifiers on page 96 describes device and device identifiers for
PCIe cards. Device identifiers are case-sensitive.
Note – PCIe names in ILOM messages are displayed with the full FRU name, such
as /SYS/MB/PCIE0.
Note – In the Solaris OS, PCIe slot addresses are associated with CMP modules. The
PCIe slot address in the Solaris OS might change if you add or remove CMP
modules, or if a CMP module is brought offline. For more information, see the
SPARC Enterprise T5440 Server Product Notes.
Related Information
■ “Managing Faults” on page 9
■ “PCIe Slot Configuration Guidelines” on page 97
■ “System Bus Topology” on page 162
■ “Performing Node Reconfiguration” on page 155
TABLE: PCIe Device Identifiers
Device Device Identifier Notes
PCIe0 /SYS/MB/PCIE0 x8 slot
PCIe1 /SYS/MB/PCIE1 x16 slot operating at x8
PCIe2 /SYS/MB/PCIE2 x8 slot
PCIe3 /SYS/MB/PCIE3 x8 slot
PCIe4
(XAUI0) /SYS/MB/PCIE4 or
/SYS/MB/XAUI0 x8 slot; shared with XAUI slot
PCIe5
(XAUI1) /SYS/MB/PCIE5 or
/SYS/MB/XAUI1 x8 slot; shared with XAUI slot
PCIe6 /SYS/MB/PCIE6 x16 slot operating at x8
PCIe7 /SYS/MB/PCIE7 x8 slot
