Returning the Server to Operation 151
FIGURE: Inserting the System Into the Rack
2. Lift the server up and insert the inner rails into the inner slide assemblies.
Ensure that the inner rails are horizontal when the inner rails enter the inner slide
assemblies.
3. Ensure that the inner rails are engaged with the ball-bearing retainers on both
inner slide assemblies.
Note – If necessary, support the server with the mechanical lift while aligning the
inner rails parallel to the rack-mounted inner slide assemblies.
▼ Slide the Server Into the Rack
1. Press the inner rail release buttons ( FIGURE: Slide Rail Release Button Location
on page 152 ) on both sides of the server.
