Servicing Customer-Replaceable Units
109
■
If the show faulty command does not report a fault with a UUID, then you
do not need to proceed with the following step because the fault is cleared.
6. Run the set command.
▼ Add FB-DIMMs
If you are upgrading the system with additional FB-DIMMs, use this procedure.
Before you begin, complete these tasks:
■
Read the section,
“Safety Information” on page 59
■
Read the sections,
“Supported FB-DIMM Configurations” on page 110
and
“FB-DIMM Device Identifiers” on page 112
■
Power off the server using one of the methods described in the section,
.
■
“Extend the Server to the Maintenance Position” on page 66
■
“Perform Electrostatic Discharge – Antistatic Prevention Measures” on page 69
■
“Remove the Top Cover” on page 69
■
“Remove a CMP/Memory Module” on page 99
1. Unpackage the FB-DIMMs and place them on an antistatic mat.
2. Ensure that the ejector tabs are in the open position.
3. Line up the FB-DIMM with the connector.
Align the FB-DIMM notch with the key in the connector. This ensures that the
FB-DIMM is oriented correctly.
/SP/faultmgmt/0 | timestamp | Dec 14 22:43:59
/SP/faultmgmt/0/ | sunw-msg-id | SUN4V-8000-DX
faults/0 | |
/SP/faultmgmt/0/
| uuid
| 3aa7c854-9667-e176-efe5-e487e520
faults/0 | | 7a8a
/SP/faultmgmt/0/
| timestamp
| Dec 14 22:43:59
faults/0 | |
-> set /SYS/MB/CPU0/CMP0/BR0/CH1/D0 clear_fault_action=True
Are you sure you want to clear /SYS/MB/CPU0/CMP0/BR0/CH1/D0 (y/n)? y
Set ’clear_fault_action’ to ’true
