Servicing Customer-Replaceable Units 81
Servicing Fan Trays
Four fan trays are located toward the front of the server, arranged in two N+1
redundant pairs. Each fan tray contains a fan mounted in an integrated,
hot-swappable CRU. If a fan tray fails, replace it as soon as possible to maintain
server availability.
Caution – Hazardous moving parts. Unless the power to the server is completely
shut down, the only service permitted in the fan compartment is the replacement of
the fan trays by trained personnel.
Related Information
■ “Identifying Server Components” on page 1
■ “Managing Faults” on page 9
■ “Powering Off the System” on page 63
■ “Hot-Pluggable and Hot-Swappable Devices” on page 72
■ “Fan Tray Device Identifiers” on page 84
■ “Fan Tray Fault LED” on page 84
■ “Server Components” on page 173
▼ Remove a Fan Tray (Hot-Swap)
Before you begin, complete these tasks:
■ Read the section, “Safety Information” on page 59 .
■ Perform the task, “Extend the Server to the Maintenance Position” on page 66 .
■ Perform the task, “Perform Electrostatic Discharge – Antistatic Prevention
Measures” on page 69 .
Do the following :
1. Identify the fan tray to be removed.
See “Fan Tray Device Identifiers” on page 84 and “Fan Tray Fault LED” on
page 84 .
2. Press the fan tray latches toward the center of the fan tray and pull the fan tray
up and out of the system.
