Servicing Customer-Replaceable Units 97
PCIe Slot Configuration Guidelines
Use the guidelines in TABLE: Supported CMP/Memory Module Configurations on
page 104 to spread the load evenly across CMP/memory modules. If a slot is already
populated with a device, install a new device in the next available slot, in the order
indicated.
External I/O Expansion Unit PCIe Link cards must be placed in a PCIe slot with a
CMP/memory module pair present as follows:
■ PCIe Slots 0 and 1 require CMP/Memory pair 0.
■ PCIe Slots 4 and 5 require CMP/Memory pair 1.
■ PCIe Slots 2 and 3 require CMP/Memory pair 2.
■ PCIe Slots 6 and 7 require CMP/Memory pair 3.
Related Information
■ “PCIe Device Identifiers” on page 96
■ “System Bus Topology” on page 162
■ “I/O Fabric in 2P Configuration” on page 164
■ “I/O Fabric in 4P Configuration” on page 165
TABLE: PCIe Slot Configuration Guidelines
PCIe/XAUI Card Type
Number of CMP/Memory
Modules
Installation Order Notes
10 GBit Ethernet (XAUI)
card 1, 2, 3 or 4 Slot 4, 5 Install XAUI cards first.
External I/O Expansion
Unit PCIe Link card 2 Slot 0, 4, 1, 5 Maximum of 4 cards; install in order
shown.
4 Slot 0, 4, 2, 6, 1, 5, 3, 7 Maximum of 8 cards; install in order
shown.
All other devices *
* These are guidelines to spread out the I/O load across multiple CMP/memory module pairs. These are not configuration restrictions.
2 Slot 0, 4, 1, 5, 2, 6, 3, 7 Maximum of 8 cards; install in order
shown.
4 Slot 0, 4, 2, 6, 1, 5, 3, 7 Maximum of 8 cards; install in order
shown.
