80 SPARC Enterprise T5440 Server Service Manual • July 2009
Related Information
■ “Hard Drive LEDs” on page 80
Hard Drive LEDs
FIGURE: Hard Drive LEDs
The front and rear panel Service Required LEDs are also lit if the system detects a
hard drive fault.
Related Information
■ “Hard Drive Device Identifiers” on page 79
TABLE: Hard Drive Status LEDs
No. LED Color Notes
1 Ready
-to-Remove Blue This LED is lit to indicate that a hard drive
can be removed safely during a hot-plug
operation.
2 Service
Required Amber This LED is lit when the system is running
and the hard drive is faulty.
3 OK/Activity Green This LED lights when data is being read
from or written to the hard drive.
