132 SPARC Enterprise T5440 Server Service Manual • July 2009
■ “Servicing the Fan Tray Carriage” on page 129
▼ Remove the Hard Drive Backplane
Before you begin, complete these tasks:
■ Read the section, “Safety Information” on page 59 .
■ Power off the server, using one of the methods described in the section, “Powering
Off the System” on page 63 .
■ “Extend the Server to the Maintenance Position” on page 66
■ “Perform Electrostatic Discharge – Antistatic Prevention Measures” on page 69
■ “Remove the Top Cover” on page 69
■ “Remove a Hard Drive” on page 77
Note – You must remove all four hard drives from the server. Note the location of
each hard drive you remove. You must re-install each hard drive in the correct bay.
■ “Remove a Fan Tray” on page 83
Note – You must remove all four fan trays.
■ “Remove the Fan Tray Carriage” on page 129
Do the following:
1. Remove the flex cable retainer.
Loosen the captive No.2 Phillips screw and lift the retainer up and out of the
chassis.
2. Unplug the cable from the hard drive backplane.
3. Loosen the three captive No. 2 Phillips screws.
