120 SPARC Enterprise T5440 Server Service Manual • July 2009
Next Steps
■ “Install the Front Bezel” on page 117
■ “Install the Top Cover” on page 150
■ “Slide the Server Into the Rack” on page 151
■ “Power On the Server” on page 153
Servicing the Service Processor
The service processor module contains the service processor firmware, IDPROM, and
system battery.
Related Information
■ “Servicing the IDPROM” on page 123
■ “Servicing the Battery” on page 125
▼ Remove the Service Processor
Before you begin, complete these tasks:
■ Read the section, “Safety Information” on page 59 .
■ Power off the server using one of the methods described in the section, “Powering
Off the System” on page 63 .
■ “Extend the Server to the Maintenance Position” on page 66
■ “Disconnect Power Cords From the Server” on page 65
■ “Perform Electrostatic Discharge – Antistatic Prevention Measures” on page 69
■ “Remove the Top Cover” on page 69
Do the following:
1. Ensure that the power cords are disconnected from the server.
2. Loosen the two captive No. 2 Phillips screws securing the service processor to
the motherboard.
