Servicing Field-Replaceable Units 131
FIGURE: Installing the Fan Tray Carriage
2. Secure the seven captive No. 2 Phillips screws
3. Install the nine No. 1Phillips screws.
Next Steps
■ “Install a Fan Tray” on page 84
Note – Install all four fan trays.
■ “Install the Top Cover” on page 150
■ “Slide the Server Into the Rack” on page 151
■ “Power On the Server” on page 153
Servicing the Hard Drive Backplane
The hard drive backplane provides the power and data interconnect to the internal
hard drives.
Related Information
■ “Servicing Hard Drives” on page 72
