SPARC Enterprise T5440 Server Service Manual • July 2009

1. At the Solaris prompt, issue the cfgadm -al command to list all drives in the

device tree, including drives that are not configured. Type:

This command should identify the Ap_id for the hard drive you wish to remove,
as in

CODE EXAMPLE: Sample Ap_id Output on page 75

2. Issue the cfgadm -c unconfigure command to unconfigure the disk.

For example, type:

where c0:dsk/c0t1d1 is the disk that you are trying to unconfigure.

3. Wait until the blue Ready-to-Remove LED lights.

This LED will help you identify which drive is unconfigured and can be removed.

4. On the drive you plan to remove, push the hard drive release button to open the

latch (

FIGURE: Removing a Hard Drive on page 74

FIGURE:

Removing a Hard Drive

Caution –

The latch is not an ejector. Do not bend the latch too far. Doing so can

damage the latch.

# cfgadm -al

# cfgadm -c unconfigure c0::dsk/d1t1d1
