FIGURE: Rear Panel Features
Related Information
■ “Front Panel Diagram” on page 3
■ “Rear Panel LEDs” on page 7
■ “Ethernet Port LEDs” on page 8
■ “Detecting Faults Using LEDs” on page 30
Figure Legend
1 Power supplies
2 Serial port
3 Serial management port
4 System status LEDs
5 USB ports
6 Network management port
7 Gigabit Ethernet ports
