Servicing Customer-Replaceable Units

113

FB-DIMM Fault Button Locations

FIGURE: FB-DIMM Fault Button Locations on page 114

shows the location of the

FB-DIMM fault buttons on the CMP module and the memory module. Press this
button to illuminate the fault indicator on the module. Replace the FB-DIMM
identified by the indicator.

Note –

You must replace a faulty FB-DIMM with an identical part (same part

number). See

“Supported FB-DIMM Configurations” on page 110

for more

information.
