112 SPARC Enterprise T5440 Server Service Manual • July 2009
FB-DIMM Device Identifiers
TABLE: FB-DIMM Configurations and Device Identifiers on page 112 describes
device and device identifiers for FB-DIMMs on a CMP and memory module pair.
Device identifiers are case-sensitive.
The FB-DIMM address follows the same convention as the CMP or memory module
upon which it is mounted. For example, /SYS/MB/CPU0/CMP0/BR1/CH0/D0 is the
device identifier for the FB-DIMM mounted at J792 on CMP module 0.
Related Information
■ “Managing Faults” on page 9
■ “Supported FB-DIMM Configurations” on page 110
■ “FB-DIMM Fault Button Locations” on page 113
■ “Performing Node Reconfiguration” on page 155
TABLE: FB-DIMM Configurations and Device Identifiers
Location FB-DIMM Device Identifiers
Connector
Number
FB-DIMM Group
CMP module /SYS/MB/CPUx/CMPx/BR1/CH0/D0
/SYS/MB/CPUx/CMPx/BR1/CH1/D0
/SYS/MB/CPUx/CMPx/BR0/CH0/D0
/SYS/MB/CPUx/CMPx/BR0/CH1/D0
Motherboard connector J792
J896
J585
J687 Group 1 *
(4 FB-DIMMs)
* Minimum configuration.
Memory module /SYS/MB/MEMx/CMPx/BR1/CH1/D2
/SYS/MB/MEMx/CMPx/BR1/CH1/D3
/SYS/MB/MEMx/CMPx/BR1/CH0/D2
/SYS/MB/MEMx/CMPx/BR1/CH0/D3 J1471
J1573
J1066
J1167 Group 2
(4 FB-DIMMs)
/SYS/MB/MEMx/CMPx/BR0/CH1/D2
/SYS/MB/MEMx/CMPx/BR0/CH1/D3
/SYS/MB/MEMx/CMPx/BR0/CH0/D2
/SYS/MB/MEMx/CMPx/BR0/CH0/D3 J847
J948
J660
J762 Group 3
(8 FB-DIMMs)
/SYS/MB/MEMx/CMPx/BR0/CH1/D1
/SYS/MB/MEMx/CMPx/BR0/CH0/D1
/SYS/MB/MEMx/CMPx/BR1/CH0/D1
/SYS/MB/MEMx/CMPx/BR1/CH1/D1
Motherboard connector J746
J511
J927
J1344
