Servicing Field-Replaceable Units

117

FIGURE:

Removing the Front Bezel

Note –

Avoid bending the bezel by gradually pulling it from the middle and both

ends simultaneously.

▼ Install the Front Bezel

1. Align the bezel with the chassis front panel.

2. Press the bezel onto the front panel.

The bezel is oriented with four guide pins, and is secured with three snap-in posts.

Next Steps

■
