32 SPARC Enterprise T5440 Server Service Manual • July 2009
Related Information
■ “Diagnostic Flowchart” on page 11
■ “Detecting Faults Using LEDs” on page 30
■ “ILOM-to-ALOM CMT Command Reference” on page 53
■ SPARC Enterprise T5440 Server Installation and Setup Guide
■ SPARC Enterprise T5440 Server Administration Guide
■ Integrated Lights Out Manager 3.0 Supplement for SPARC Enterprise T5440 Server
Detecting Faults Using ILOM show faulty
Command
Use the ILOM show faulty command to display the following kinds of faults:
CMP module
or memory
module • Service Required LED (front and rear
panel)
• CMP Module Fault LED or Memory
Module Fault LED
A lit CMP module or memory module fault LED
might indicate a problem with an FB-DIMM
installed on the CMP module, or a problem with
the CMP module itself.
See these sections:
•
“Front Panel LEDs” on page 4
• “Rear Panel LEDs” on page 7
• “Servicing CMP/Memory Modules” on page 98
• “Servicing FB-DIMMs” on page 104
FB-DIMM • Service Required LED (front and rear
panel)
• CMP Module Fault LED or Memory
Module Fault LED
• FB-DIMM Fault LED (CMP and
memory modules) (when FB-DIMM
Locate button is pressed)
See these sections:
•
“Front Panel LEDs” on page 4
• “Rear Panel LEDs” on page 7
• “Servicing FB-DIMMs” on page 104
• “FB-DIMM Fault Button Locations” on page 113
Other
components • Service Required LED (front and rear
panel)
Not all components have an individual component
Fault LED. If the Service Required LED is lit, use
the show faulty command to obtain additional
information about the component affected. See
these sections:
•
“Front Panel LEDs” on page 4
• “Rear Panel LEDs” on page 7
TABLE: System Faults and Fault LED States (Continued)
Component Fault Fault LEDs Lit Additional Information
