Jumpers & Switch Settings
Page 44 MDE-4375 CFN Series Site Controller III Start-Up Manual · June 2005
Island Card Reader
DIP Switches
The island card reader has an S2 bank of 10 dip switches. Switches 1 through 6 provide
functional settings; switches 7 through 10 are address settings. The settings and functions are
shown in the following tables.
ICR Software
An address must be set up to identify the island card reader. This address is a unique identifier
for when multiple ICRs are connected on the same RS-485 line. Up to 16 units can be used on
the same line (there are 16 addresses). Addressing should start at 1 and continue sequentially
through 16. The physical wiring order does not have to correspond with the address order (the
first unit on the RS-485 line does not have to be address 1). The chart below gives the switch
setting for the address selections.
Note: The standalone receipt printer (when used) is addressed as an island card reader; be
sure to use an address different from any ICR.
An S3 switch enables the diagnostic mode of the ICR. Diagnostic mode is enabled when the
switch is in the down position.
Switch Function
S2-1 No function
S2-2 DPT Open = enables decimal point on the keypad.
Closed = the decimal point acts as a CLEAR key.
S2-3 DIS Open = two lines of display are displayed.
Closed = only one line of display is displayed.
S2-4 INSRT Open = insertion magnetic card reader.
Closed = swipe magnetic card reader or optical reader.
S2-5 GATE Open = island card reader.
Closed = gate controller.
S2-6 OPT Open = optical reader.
Closed = magnetic card reader.
Address
S2-7 S2-8 S2-9 S2-10
Address
S2-7 S2-8 S2-9 S2-10
ADDR4 ADDR3 ADDR2 ADDR1 ADDR4 ADDR3 ADDR2 ADDR1
1 Closed Closed Closed Closed 9 Open Closed Closed Closed
2 Closed Closed Closed Open 10 Open Closed Closed Open
3 Closed Closed Open Closed 11 Open Closed Open Closed
4 Closed Closed Open Open 12 Open Closed Open Open
5 Closed Open Closed Closed 13 Open Open Closed Closed
6 Closed Open Closed Open 14 Open Open Closed Open
7 Closed Open Open Closed 15 Open Open Open Closed
8 Closed Open Open Open 16 Open Open Open Open
Switch Function
S3 Up = normal; Down = test mode
