Chapter 3: Functional Description 3–41
MegaCore Verification
© March 2009 Altera Corporation DDR and DDR2 SDRAM Controller Compiler User Guide
Manual Timings
The manual timing settings do not need to be changed under normal circumstances.
For more information on the manual timing settings, refer to “Manual Timing
Settings” on page A–1 .
MegaCore Verification
MegaCore verification involves simulation testing and hardware testing.
Simulation Testing
Altera has carried out extensive random, directed tests with functional test coverage
using industry-standard Denali models to ensure the functionality of the DDR and
DDR2 SDRAM controller. In addition, Altera has carried out a wide variety of gate-
level tests of the DDR and DDR2 SDRAM controllers to verify the post-compilation
functionality of the controllers.
Hardware Testing
Table 3–25 shows the Altera development boards on which Altera hardware tested
the DDR and DDR2 SDRAM controllers.
Table 3–25. Altera Development Boards
Development Board Altera Device Memory Device
Stratix II High-Speed IO Development Board EP2S60F1020C3 Micron DDR2-533 DIMM (MT8HTF3272AG-
53EB3ES)
Stratix II PCI Development Board EP2S60F1020C3 Infineon DDR400 SO-DIMM
(HYS64D32020GDL-5-B)
Stratix PCI Development Board EP1S25F1020C5 Infineon DDR400 SO-DIMM
(HYS64D32020GDL-5-B)
Stratix PCI Development Board, Professional
Edition EP1S60F1020C6 Micron DDR333 SO-DIMM
(MT8VDDT3264HG-335C2)
Stratix GX High-Speed Development Board EP1SGX25FF1020C6ES Micron DDR400 DIMM
(MT16VDDT3264AG-40BB5)
Internal Stratix Memory Test Board EP1S25F780C5 Micron DDR400 DIMM
(MT16VDDT3264AG-40BB5)
Nios Development Board, Cyclone II
(EP2C35) EP2C35F672C6 Micron 128-Mbit DDR-333 device
(MT46V16M16-6T)
Cyclone II EP2C35 PCI Development Board EP2C35F672C6 Micron 256-Mbit DDR2-533 device
(MT47H16M16BG-37E)
Cyclone II EP2C35 DSP Development Board EP2C35F672C6 Micron DDR2-533 DIMM (MT8HTF3264AY-
40EB3)
Cyclone Memory Board EP1C6Q240C6 Micron 128-Mbit DDR266 device
(MT46V8M16-75)
Internal Cyclone Memory Test Board EP1C20F400C6 Micron DDR266 DIMM
(MT16VDDT3264AG-265B1)
