IFS NS3552-8P-2S AND NS3550-2T-8S User Manual

227

ICMP Code Value

When "Specific" is selected for the ICMP code filter, you can enter a specific ICMP
code value. The allowed range is 0 to 255. A frame that hits this ACE matches this
ICMP code value.

TCP/UDP Parameters

Object

Description

TCP/UDP Source Filter

Specify the TCP/UDP source filter for this ACE.

Any: No TCP/UDP source filter is specified (TCP/UDP source filter
status is "don't-care").

Specific: If you want to filter a specific TCP/UDP source filter with this
ACE, you can enter a specific TCP/UDP source value. A field for
entering a TCP/UDP source value appears.

Range: If you want to filter a specific TCP/UDP source range filter with
this ACE, you can enter a specific TCP/UDP source range value. A field
for entering a TCP/UDP source value appears.

TCP/UDP Source No.

When "Specific" is selected for the TCP/UDP source filter, you can enter a specific
TCP/UDP source value. The allowed range is 0 to 65535. A frame that hits this
ACE matches this TCP/UDP source value.

TCP/UDP Source
Range

When "Range" is selected for the TCP/UDP source filter, you can enter a specific
TCP/UDP source range value. The allowed range is 0 to 65535. A frame that hits
this ACE matches this TCP/UDP source value.

TCP/UDP Destination
Filter

Specify the TCP/UDP destination filter for this ACE.

Any: No TCP/UDP destination filter is specified (TCP/UDP destination
filter status is "don't-care").

Specific: If you want to filter a specific TCP/UDP destination filter with
this ACE, you can enter a specific TCP/UDP destination value. A field
for entering a TCP/UDP destination value appears.

Range: If you want to filter a specific range TCP/UDP destination filter
with this ACE, you can enter a specific TCP/UDP destination range
value. A field for entering a TCP/UDP destination value appears.

TCP/UDP Destination
Number

When "Specific" is selected for the TCP/UDP destination filter, you can enter a
specific TCP/UDP destination value. The allowed range is 0 to 65535. A frame
that hits this ACE matches this TCP/UDP destination value.

TCP/UDP Destination

Range

When "Range" is selected for the TCP/UDP destination filter, you can enter a
specific TCP/UDP destination range value. The allowed range is 0 to 65535. A
frame that hits this ACE matches this TCP/UDP destination value.

TCP FIN

Specify the TCP "No more data from sender" (FIN) value for this ACE.

0: TCP frames where the FIN field is set must not be able to match this
entry.

1: TCP frames where the FIN field is set must be able to match this
entry.

Any: Any value is allowed ("don't-care").

TCP SYN

Specify the TCP "Synchronize sequence numbers" (SYN) value for this ACE.

0: TCP frames where the SYN field is set must not be able to match this
entry.

1: TCP frames where the SYN field is set must be able to match this
entry.

Any: Any value is allowed ("don't-care").

TCP RST

Specify the TCP "Reset the connection" (RST) value for this ACE.

0: TCP frames where the RST field is set must not be able to match this
entry.

1: TCP frames where the RST field is set must be able to match this
entry.

Any: Any value is allowed ("don't-care").

TCP PSH

Specify the TCP "Push Function" (PSH) value for this ACE.

0: TCP frames where the PSH field is set must not be able to match this
entry.

1: TCP frames where the PSH field is set must be able to match this
entry.

Any: Any value is allowed ("don't-care").

TCP ACK

Specify the TCP "Acknowledgment field significant" (ACK) value for this ACE.

0: TCP frames where the ACK field is set must not be able to match this
entry.

1: TCP frames where the ACK field is set must be able to match this
entry.
