Averaging Time and Refresh Cycle
The LS-7600 Series averages measured values in a moving averaging method, thus
making it possible to output the measured values within a short time.
The following table lists the averaging time, the number of moving averaging data items,
and the refresh cycle of a target according to the number of averaging measurements.
Number of
averaging
measurements
Averaging time (ms)
Number of moving
data samples
Refresh cycle (ms)
1 0.42 1 0.42
2 0.83 2 0.83
4 1.67 2 0.83
8 3.33 2 0.83
16 6.67 2 0.83
32 13.33 2 0.83
64 26.67 2 0.83
128 53.33 2 0.83
256 106.67 4 1.67
512 213.33 8 3.33
1024 426.67 16 6.67
2048 853.33 32 13.33
4096 1706.67 64 26.67
❈Measurement averaging time does not indicate the measuring response time of the
LS-7600 Series.
Refer to Measuring Response Time on page 9-5 for details.
Example: If the averaging number is eight, the LS-7600 Series will output the data as
shown below.
1
Internal data
(2,400 samples/s)
Output data
2 3 4 5 6 7 8 9 10 11 12 13 14
Refresh
cycle
Refresh
cycle
A B C
Measurement averaging time
Measurement averaging time
Data samples 1 through 8 are
averaged, and data A is output
Data samples 3 through 10 are
averaged, and data B is output
Data samples 5 through 12 are
averaged, and data C is output
Measurement averaging time
■
Setting Method
1
Press the [Up or Down] key and move the cursor to AVE.
2
Press the [ENT] key.
The cursor moves to the setting item.
3
Press the [Up or Down] key to set the
number of averaging measurements.
4
Press the [ENT] key.
The input value is entered and the
cursor returns to AVE.
OUT1
CALC +1 A1 +0 A2
AVE 512
MEA-MODE NORMAL
OFFSET
0.00000
