Nomenclature and functions of i/o terminals, Terminal block – KEYENCE LS-7600 User Manual
Page 150
7-2
Chapter 7 I/O Terminals
7
Nomenclature and Functions of I/O Terminals
This section provides nomenclature and functions of the I/O terminals of the LS-7600
Series.
Types of I/O Terminals
The LS-7600 Series has three types of I/O terminals. Use them according to the func-
tion used and the environment.
Connector I/O
Terminal block
VIDEO output (RCA jack)
Terminal Block
Applicable Cable Specifications
AWG14~24
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
Terminal number
