Chapter 5 Function Settings
5
■
Output Waiting Voltage
Take the following steps to set the voltage to be output when the display shows “---.-----.”
1
Press the [Up or Down] key and move the cursor to A-CONT.
2
Press the [ENT] key.
The cursor moves to the setting item.
3
Press the [Up or Down] key and
select the setting item.
4
Press the [ENT] key.
The input item is entered and the cursor
returns to A-CONT.
Comparator Output Setting
Adjust the comparator output settings.
Setting Range
The following comparator output settings are available.
• Strobe output time: Select the ON-time of the strobe output (i.e., one-shot output
time) from 0.4, 0.8, 1.6, 3.3, 6.6, 13.3, and 26.6 ms.
• Output logic: Set the logic of the comparator output and WAITING output to NO
(normally open) or NC (normally closed).
• OFF-delay time: Select the OFF-delay time of the comparator output from OFF,
0.4, 0.8, 1.6, 3.3, 6.6, 13.3 and 26.6 ms.
■
Strobe Output Time
Take the following steps to set the ON-time of strobe output.
1
Press the [Up or Down] key and move the cursor to STROBE-T.
2
Press the [ENT] key.
The cursor moves to the setting item.
OUT1
A-UNIT 1000um/V
A-SET OFF
A-CONT +10.5V
OUT1
STOBE-T 0.4ms
OUT-SET N.O.
OFF-DLY OFF
3
Press the [Up or Down] key and
select the setting item.
4
Press the [ENT] key.
The input item is entered and the cursor
returns to STOBE-T.
