4-2
Chapter 4 Operation Control
4
▲ ▼
Switching Display Screen
The following section provides information on how to display an OUT1 or OUT2 measured
value or both on the LCD monitor. Furthermore, it provides information on trend graph,
statistical processing and NG RECORD display. The LCD monitor is operable through the
panel keys as well as the remote control console.
Measured Value Display
The OUT1 or OUT2 measured value or both can be displayed at a time. If both values are
displayed at a time, the trend graph or statistical processing of the values can be displayed.
■
Switching between Single Value Display and Both Display
The RUN mode display will change in sequence whenever the [ENT] key (Up or
Down key) is pressed.
OUT1 Single Display
OUT2 Single Display
Both Value Display
OUT1
12.34560
UPPER 1.00000
STANDARD 12.00000
LOWER
–1.00000
CAM1
RUN
P – 00
01/02/18
17:50:42
GO
The measured values vary
between the set LIMITS.
OUT2
23.45670
UPPER 1.00000
STANDARD 23.00000
LOWER
–1.00000
CAM1
RUN
P – 00
01/02/18
17:50:42
GO
OUT1
12.34560
UP 1.00000
STD 12.00000
LO –1.00000
NORMAL 512
OUT2
23.45670
UP 1.00000
STD 23.00000
LO –1.00000
NORMAL 512
CAM1
RUN
P – 00
AREA1
HEAD1
DIA
AREA2
HEAD1
DIA
A1 2
A2 2
01/02/18
17:50:42
▲ ▼
