9-2
Chapter 9 Specifications
9
Specifications
Controller
Display type
Minimum display unit
Display range
Measuring position monitor
Tolerance comparator output display
Alarm output
5-level comparator output
Comparator waiting output
Strobe output
Timing input
Reset input
Auto zero input
Program selection input
Statistical processing input
Analog output
Timing input
Reset input
Auto zero input
Statistical processing input
RS-232C interface
Model
Number of connectable measuring heads
5-level comparator output
Comparator waiting output
Strobe output
Statistical processing output
Function output
BCD output
BCD selection output
BCD selection input
Electrical
rating ( ❈2)
Environment
resistance
Power supply voltage
Current consumption
Enclosure rating
Ambient temperature
Relative humidity
SUB
mode
( ❈1)
BCD
mode
( ❈1)
LS-7601
2 (interchangeable)
TFT5.5-type LCD
Backlight: Cold cathode fluorescent lamp (with an average life of 40,000 hours)
0.01µm to 100µm (7 selectable levels)
±99.99999~±9999.9mm (varies with the minimum display units)
Monitor images
5-level liquid crystal display (LCD)
NPN open collector output (N.C.)
OUT1 NPN open collector output
OUT1 non-voltage input
Non-voltage input x 4
OUT1 non-voltage input
±10 V x 2 outputs
OUT2 NPN open collector output
NPN open collector output x 2
Focus, area check, or difference selectable, NPN open collector output x 2
Measuring data output (sign + 7 digit) OUT1/OUT2 selectable, NPN open collector output
NPN open collector output
Non-voltage input
Out2 non-voltage input
Measurement data output and control I/O for printer
(Baud rate selectable up to 15200 bps)
Conforming to NTSC (RCA connector)
Simultaneous measurement, area setting, calculation, averaging, calibration, 16 program
memory, measurement, automatic zero, print-out, abnormal value elimination, transparent
object measurement, measurement point display, group processing, NG error log, trend
display, statistical processing, mutual interference prevention, and application functions
24V DC ±10%
1.2A max
IP64 (panel surface only)
0 to +40°C (32 to 104°F), No freezing
35 to 85% RH, No condensation
Approx. 1,010 g Weight
Te
rminal b
loc
k
Displa
y
Connector I/O
Main functions
Video output
❈1: Select either the SUB or BCD mode.
❈2: AC power supply is available through the LS-S11 (AC Power Supply Stand).
The terminal block has a maximum open collector output of 100 mA (at 40 V max.) with a maximum residual
voltage of 1 V. The connector I/O has a maximum NPN open collector output of 30 mA (at 30 V max.) with a
maximum residual voltage of 1 V. The non-voltage input has a maximum rated ON voltage of 1 V and
maximum OFF current of 0.6 mA.
