KEYENCE LS-7600 User Manual
Page 144
6-10
Chapter 6 Environment Settings
6
Check on Intensity of LED Light Source
With the LED inspection function, the distribution of light will appear on the LCD monitor
as shown below, which makes it possible to check the change of light intensity after the
LS-7600 Series is installed.
100%
100%
100%
100%
100%
100%
100%
100%
The distribution of light is uniform.
Indicates that 100% light is distributed.
(Varies by a few percent according to the unit.)
This bar indicates 5% intensity.
80%
80%
80%
80%
80%
80%
80%
80%
The distribution of light is with a
20% drop of intensity.
