Page 77

5-15
Chapter 5 Function Settings
5
SEG (Segment) Setting
(1) Press the [Up or Down] key and input
the start edge (or start pitch) number.
AREA1
HEAD
1
AREA
+2
E
+3E
A-DISP ON
FOCUS 5
A-TEST OFF
(2) Press the [Left or Right] key and
move the cursor to the end edge (or
end pitch) number.
AREA1
HEAD
1
AREA
+2
E
+3E
A-DISP ON
FOCUS 5
A-TEST OFF
(3) Press the [Up or Down] key and input
the edge pitch (or end pitch) number.
(4) Press the [ENT] key.
The input values are entered and the
cursor moves to AREA.
AREA1
HEAD
1
AREA
+2E
+3
E
A-DISP ON
FOCUS 5
A-TEST OFF
Note:
• The duplicated designation of an edge or pitch number will set the meas-
ured value to 0.
• If edges or pitches are designated in reverse order, negative measured
values will be obtained.
Area Display
The area cursor on the target viewer can be turned ON or OFF. If the cursors for both
AREA1 and AREA2 are turned OFF, no scanning line will be displayed.
When both CAMERA 1 and CAMERA 2 are selected in Switching Cameras (page 4-8), the
area cursors cannot be hidden.
■
Setting Method
1
Select A-DISP and press the [ENT]
key.
The cursor moves to the setting item.
AREA1
HEAD
1
AREA
DIA
A-DISP
ON
FOCUS 5
A-TEST OFF
