Kontron COMe Starterkit Eval T2 User Manual
Page 25
COM Express Interfaces
Pin#
Type 10 Description
Type 2 Description
Type 6 Description
C8
-
IDE_D2
GND
C9
-
IDE_D13
USB_SSRX2-
C10
-
IDE_D1
USB_SSRX2+
C11
-
GND(FIXED)
GND(FIXED)
C12
-
IDE_D14
USB_SSRX3-
C13
-
IDE_IORDY
USB_SSRX3+
C14
-
IDE_IOR#
GND
C15
-
PCI_PME#
DDI1_PAIR6+
C16
-
PCI_GNT2#
DDI1_PAIR6-
C17
-
PCI_REQ2#
RSVD
C18
-
PCI_GNT1#
RSVD
C19
-
PCI_REQ1#
PCIE_RX6+
C20
-
PCI_GNT0#
PCIE_RX6-
C21
-
GND(FIXED)
GND(FIXED)
C22
-
PCI_REQ0#
PCIE_RX7+
C23
-
PCI_RESET#
PCIE_RX7-
C24
-
PCI_AD0
DDI1_HPD
C25
-
PCI_AD2
DDI1_PAIR4 +
C26
-
PCI_AD4
DDI1_PAIR4-
C27
-
PCI_AD6
RSVD
C28
-
PCI_AD8
RSVD
C29
-
PCI_AD10
DDI1_PAIR5+
C30
-
PCI_AD12
DDI1_PAIR5-
C31
-
GND(FIXED)
GND(FIXED)
C32
-
PCI_AD14
DDI2_CTRLCLK_AUX+
C33
-
PCI_C/BE1#
DDI2_CTRLDATA_AUX-
C34
-
PCI_PERR#
DDI2_DDC_AUX_SEL
C35
-
PCI_LOCK#
RSVD
C36
-
PCI_DEVSEL#
DDI3_CTRLCLK_AUX+
C37
-
PCI_IRDY#
DDI3_CTRLDATA_AUX-
C38
-
PCI_C/BE2#
DDI3_DDC_AUX_SEL
C39
-
PCI_AD17
DDI3_PAIR0+
C40
-
PCI_AD19
DDI3_PAIR0-
C41
-
GND(FIXED)
GND(FIXED)
C42
-
PCI_AD21
DDI3_PAIR1+
C43
-
PCI_AD23
DDI3_PAIR1-
C44
-
PCI_C/BE3#
DDI3_HPD
C45
-
PCI_AD25
RSVD
C46
-
PCI_AD27
DDI3_PAIR2+
C47
-
PCI_AD29
DDI3_PAIR2-
C48
-
PCI_AD31
RSVD
C49
-
PCI_IRQA#
DDI3_PAIR3+
C50
-
PCI_IRQB#
DDI3_PAIR3-
C51
-
GND(FIXED)
GND(FIXED)
C52
-
PEG_RX0+
PEG_RX0+
C53
-
PEG_RX0-
PEG_RX0-
PICMG
®
COM Express
®
Carrier Board Design Guide
Rev. 2.0 / December 6, 2013
25/218
