Appendix E: Revision History
13. Appendix E: Revision History
Table 79: Revision History
Revision Date Author Changes
1.00 RC1.0 Jan 16, 2009 C. Eder
1.10 beta0.1 Sept 14 2012 M. Unverdorben Exchanged “Trademark” against “Registered” for COM Express
Added Chapters:
Interface description
– DisplayPort
– MXM
– USB 3.0
– embedded DisplayPort
– SPI Bus
– General Purpose Serial Interface
– CAN
Power and Reset:
– Design Considerations for Carrier Boards containing FPGAs or other
programmable logic
Routing Rules for High-Speed Differential Interfaces
– USB 3.0 Trace Routing Guidelines
– DisplayPort Trace Routing Guidelines
1.10 beta0.2 Sept 26, 2012 M. Unverdorben Added Text for embedded DisplayPort
Exchanged Chapter 7.1 Mechanical Considerations → Form Factors
Added Text and drawing for 6.4 Trace-Lenght Extensions Considerations
Added MXM Text
Expanded Chapter 2 with additional pin-out types drawings and tables
Updated Chapter 2 according to feedback
Again updated Chapter 2 according to feedback
updated General Purpose Serial Interface and CAN
updated Abbreviations
changed mechanical considerations according Bill's suggestion (2012-10-16)
changed eDP according to Ben's suggestion (2012-10-12)
2.0 beta 0.1 Jan 07, 2013 M. Unverdorben Changed to 2.0 revisions
shifted TV-out to the Appendix
reworked audio interfaces to have more focus on HDA
added different generations at PCIe chapter (2.2)
added type 6 to PCIe description (chapter 2.2.1)
exchanged SM Bus buffer schematic
remove I2C bus example (EEPROM) in SMB chapter
2.0 beta 0.2 Jan 18, 2013 M. Unverdorben Reconfigured chapter order of SDVO / HDMI → Digital Display Interface
updated abbreviation table
updated PCIe chapter (2.3)
updated and corrected PEG (2.4)
corrected LAN and USB chapter
corrected SATA reference schematics
corrected and updated VGA
switched on numbering in the appendices
add note to LPC firmware hub, shifted chapter to deprecated chapters
changed power domain on I2C reference schematic
updated miscellaneous signals chapter
added wide range for mini on chapter 3.0
shifted PCI chapter to the end of interfaces
2.0 beta 0.5 Feb 18, 2013 M. Unverdorben Changed Power button behavior description
Added connector vendors Foxconn and EPT
Added “Protecting COM.0 Pins Reclaimed From the VCC_12V Pool'
Added USB 3.0 Trace Routing Guidelines
Added DP Trace Routing Guidelines
Added SDIO Interface Multiplexed with GPIOs
Added text for DDI
Added missing References
changed MXM schematic (SMB_S0)
exchanged LPC SuperI/O example to W83267DHG-P
Corrected SDIO/GPIO description according to Chris Lewis suggestions
2.0 beta 0.6 March, 20, 2013 M. Unverdorben Corrected errors according to “Kontron List”
Added MXM content
Added USB power control via SPI_POWER
