COM Express Interfaces
2.1.1.
Connector Pin-out Comparison
Table 4:
Pin-out Comparison
Pin#
Type 10 Description
Type 2 Description
Type 6 Description
A1
GND(FIXED)
GND(FIXED)
GND(FIXED)
A2
GBE0_MDI3-
GBE0_MDI3-
GBE0_MDI3-
A3
GBE0_MDI3+
GBE0_MDI3+
GBE0_MDI3+
A4
GBE0_LINK100#
GBE0_LINK100#
GBE0_LINK100#
A5
GBE0_LINK1000#
GBE0_LINK1000#
GBE0_LINK1000#
A6
GBE0_MDI2-
GBE0_MDI2-
GBE0_MDI2-
A7
GBE0_MDI2+
GBE0_MDI2+
GBE0_MDI2+
A8
GBE0_LINK#
GBE0_LINK#
GBE0_LINK#
A9
GBE0_MDI1-
GBE0_MDI1-
GBE0_MDI1-
A10
GBE0_MDI1+
GBE0_MDI1+
GBE0_MDI1+
A11
GND(FIXED)
GND(FIXED)
GND(FIXED)
A12
GBE0_MDI0-
GBE0_MDI0-
GBE0_MDI0-
A13
GBE0_MDI0+
GBE0_MDI0+
GBE0_MDI0+
A14
GBE0_CTREF
GBE0_CTREF
GBE0_CTREF
A15
SUS_S3#
SUS_S3#
SUS_S3#
A16
SATA0_TX+
SATA0_TX+
SATA0_TX+
A17
SATA0_TX-
SATA0_TX-
SATA0_TX-
A18
SUS_S4#
SUS_S4#
SUS_S4#
A19
SATA0_RX+
SATA0_RX+
SATA0_RX+
A20
SATA0_RX-
SATA0_RX-
SATA0_RX-
A21
GND(FIXED)
GND(FIXED)
GND(FIXED)
A22
USB_SSRX0-
SATA2_TX+
SATA2_TX+
A23
USB_SSRX0+
SATA2_TX-
SATA2_TX-
A24
SUS_S5#
SUS_S5#
SUS_S5#
A25
USB_SSRX1-
SATA2_RX+
SATA2_RX+
A26
USB_SSRX1+
SATA2_RX-
SATA2_RX-
A27
BATLOW#
BATLOW#
BATLOW#
A28
(S)ATA_ACT#
(S)ATA_ACT#
(S)ATA_ACT#
A29
AC/HDA_SYNC
AC/HDA_SYNC
AC/HDA_SYNC
A30
AC/HDA_RST#
AC/HDA_RST#
AC/HDA_RST#
A31
GND(FIXED)
GND(FIXED)
GND(FIXED)
A32
AC/HDA_BITCLK
AC/HDA_BITCLK
AC/HDA_BITCLK
A33
AC/HDA_SDOUT
AC/HDA_SDOUT
AC/HDA_SDOUT
A34
BIOS_DIS0#
BIOS_DIS0#
BIOS_DIS0#
A35
THRMTRIP#
THRMTRIP#
THRMTRIP#
A36
USB6-
USB6-
USB6-
A37
USB6+
USB6+
USB6+
A38
USB_6_7_OC#
USB_6_7_OC#
USB_6_7_OC#
A39
USB4-
USB4-
USB4-
A40
USB4+
USB4+
USB4+
A41
GND(FIXED)
GND(FIXED)
GND(FIXED)
A42
USB2-
USB2-
USB2-
A43
USB2+
USB2+
USB2+
